Polyurethane Shackle Bush

Get a Price/Quote

Polyurethane Shackle Bush Specification

Temperature Range
-40C to +80C

Product Type
Shackle Bush

Finish
Polished Finish

Method
Injection Moulded

Operating System
Manual installation in mechanical assemblies

Corrosion Resistant
Yes

Color
Red / Yellow / Blue (customizable)

Working Life
Up to 50,000 km or more

Material
Polyurethane

Load Capacity
Up to 3000 kg (vehicle dependent)

Dimension (L*W*H)
45mm x 32mm x 30mm (sample size; sizes available as per requirement)

Size
Available in multiple sizes as per vehicle specification

For Use In
Automobile Suspension Systems

Model No
PU-SB-102

Part Type
Suspension Bushing

Vehicle Type
Commercial & Passenger Vehicles

Connecting Type
Press Fit / Bolt On

Lubrication Type
Self-Lubricating

Noise Level
Low / Noise Dampening

Weight
Approx. 200g - 350g (varies by model/size)

Surface Treatment
Smooth / Semi-gloss

Installation
Easy Snap Fit

UV Resistance
Yes

Packaging Type
Polybag/Box

Chemical Resistance
Resistant to Oil and Grease

OEM Service
Yes

Water Absorption
Negligible

Reusability
Reusable

Flame Retardance
Standard Grade

Customization
Available on Request

Shelf Life
3 Years

Tensile Strength
22 MPa

Shore Hardness
85A

Compression Strength
Above 30 MPa

About Polyurethane Shackle Bush

Polyurethane Shackle Bush

A Polyurethane Shackle Bush is a robust and durable component used in suspension systems, particularly in vehicles, trailers, and heavy machinery. Designed to fit into shackles, it serves as a pivot point, allowing for smooth movement and articulation between the suspension and frame.

Key Features and Benefits

Superior Durability: Made from high-quality polyurethane, these bushes offer superior resistance to wear, abrasion, oils, and extreme temperatures compared to traditional rubber bushes.
Shock Absorption: The flexibility and shock-absorbing properties of polyurethane help reduce friction, minimize vibrations, and protect other suspension components from damage caused by excessive movement or stress.
High Load-Bearing Capacity: Polyurethane shackle bushes are ideal for heavy-duty applications, as they can handle high load-bearing capacities and provide longer service life, reducing the need for frequent replacements.
Resistance to Harsh Conditions: Polyurethane offers excellent performance under challenging conditions, making these bushes well-suited for demanding environments.

Applications

Polyurethane shackle bushes are commonly used in:

Off-road vehicles
Commercial trucks
Industrial equipment

Their ability to perform under heavy-duty conditions enhances stability, improves ride comfort, and contributes to the longevity of the suspension system. Polyurethane shackle bushes are an ideal choice for applications requiring durability and performance in challenging conditions.

Engineered for Longevity and Performance

The Polyurethane Shackle Bush offers a robust solution for your suspension needs, designed to withstand high loads up to 3000 kg and operate reliably in extreme temperatures ranging from -40C to +80C. With negligible water absorption and strong UV and chemical resistance, this bush dramatically reduces wear and increases the overall working life of suspension systems.

Versatile Customization and Easy Installation

Customized according to client specifications, this bush is available in multiple sizes, fits various models, and offers a choice of color finishes (red, yellow, blue). Its snap-fit and bolt-on designs ensure installation is straightforward, whether for new assembly or as a direct replacement part. Each product is securely packed in polybags or boxes for safe transport.

FAQs of Polyurethane Shackle Bush:

Q: How is the Polyurethane Shackle Bush installed in a vehicles suspension system?

A: The shackle bush is designed for manual installation using either a press-fit or bolt-on method. Its snap-fit feature simplifies the process, allowing for quick and secure fitting without specialized equipment.

Q: What benefits does polyurethane offer over traditional rubber bushings?

A: Polyurethane bushings provide enhanced resistance to oil, grease, UV rays, and chemicals, which improves durability and performance. They also offer higher load capacities, better noise dampening, and a longer working life compared to traditional rubber alternatives.

Q: Can this shackle bush be customized for specific vehicle models and color preferences?

A: Yes, the bush can be customized in size and color based on client requirements. Customization options include dimensions to fit various vehicle specifications and color choices such as red, yellow, or blue.

Q: When should a shackle bush typically be replaced?

A: It is advisable to replace the shackle bush after it has reached its working life of up to 50,000 km, or if there are signs of excess noise, play, or visible wear in the suspension system, ensuring optimal vehicle safety and performance.

Q: What is the shelf life and optimal storage conditions for this product?

A: The shackle bush has a shelf life of three years when stored in its original polybag or box packaging, kept away from direct sunlight and extreme temperatures, ensuring it remains in peak condition until installation.

Q: Where can the Polyurethane Shackle Bush be sourced from?

A: This product is manufactured, supplied, and exported from India. It can be sourced directly from the manufacturer as well as through authorized distributors and wholesalers.
